Water Supply Threaded Mechanical Cross Pipe Fitting
2.4-way water branch, grooved mechanical joint .
3.Potable water system high-strength cross .
4.Corrosion-resistant blue/silver grooved cross .
5.Precision-manufactured water mechanical cross .
6.Industrial water supply 4-way grooved joint .
7.Durable blue/silver water grooved cross .
8.Pressure-resistant potable water mechanical cross
Description
Water Supply Threaded Mechanical Cross Pipe Fitting
When you need a reliable four-way connection for your piping system, the Water Supply Threaded Mechanical Cross Pipe Fitting conveys unmatched execution and productivity. This specialized pipe fitting makes four outlet focuses at 90-degree interims, making it culminate for complex stream conveyance in fire assurance, HVAC, and mechanical applications. Our product eliminates the require for welding or threading, diminishing establishment time by up to 70% whereas guaranteeing predominant joint judgment. Each cross highlights precision-machined grooves outlined to work consistently with mechanical couplings, giving you with a association that's both solid and flexible.
Technical Specifications
Our notched mechanical cross fittings are built from high-strength pliable press adjusting to ASTM A536 Grade 65-45-12. This fabric choice guarantees extraordinary strength and resistance to water powered stun in requesting applications.
| Specification | Details |
|---|---|
| Material | Ductile Iron ASTM A536 Grade 65-45-12 |
| Size Range | 1" - 12" (DN25 - DN300) |
| Working Pressure | 300-1000 PSI (20-69 bar) |
| Groove Standard | ANSI/AWWA C606, ISO 6182 |
| Surface Treatment | Epoxy Paint, Hot Dip Galvanized |
| Operating Temperature | -40°F to 200°F (-40°C to 93°C) |
| Connection Type | Grooved Mechanical |
| Tensile Strength | Minimum 65,000 PSI |
Key Features
Superior Establishment Speed: You can introduce our notched crosses without hot work licenses or specialized welding gear. This speeds up venture completion significantly.
Vibration Resistance: The mechanical joint actually assimilates pump vibrations and warm development, ensuring your whole channeling framework from stress-related failures.
Maintenance Neighborly: Each association point permits for simple dismantling when you require to perform support or framework modifications.
Code Compliant: All fittings meet AWWA C606 measures, guaranteeing compatibility with industry-standard couplings and gaskets.
Dimensions and Specifications Table
| Size (inches) | A (Groove Width) | C (Groove Depth) | Weight (lbs) | End-to-End |
|---|---|---|---|---|
| 2" | 0.94" | 0.15" | 3.2 | 4.5" |
| 3" | 0.94" | 0.15" | 5.8 | 5.2" |
| 4" | 0.94" | 0.15" | 8.5 | 6.0" |
| 6" | 0.94" | 0.15" | 15.2 | 7.5" |
| 8" | 0.94" | 0.15" | 24.8 | 9.0" |
| 10" | 0.94" | 0.15" | 38.5 | 10.8" |
| 12" | 0.94" | 0.15" | 55.2 | 12.5" |
We manufacture each Water Supply Threaded Mechanical Cross Pipe Fitting utilizing premium bendable press that gives 12% least prolongation for predominant adaptability. The spheroidal graphite structure anticipates brittleness whereas keeping up fabulous quality characteristics.
Standard Wrap up: Ruddy epoxy paint coating offers fabulous erosion resistance for most indoor applications.
Galvanized Alternative: Hot-dip galvanized wrap up per ASTM A153 gives improved assurance in forceful situations or open air installations.
Standards and Certifications
Our fabricating forms entirely take after ISO 9001 quality administration frameworks. All groove measurements adjust to ANSI/AWWA C606 details, guaranteeing all inclusive compatibility with mechanical couplings from driving manufacturers.
Application Areas
Fire Assurance Frameworks: Perfect for sprinkler fundamental conveyance where dependable stream course is basic for life security applications.
Commercial HVAC: Idealize for chilled water and warming circles in plant rooms where you require effective stream administration around equipment.
Industrial Prepare Channeling: Reasonable for water treatment offices, mining operations, and fabricating plants requiring tough connections.
Municipal Water Frameworks: Amazing choice for dissemination systems where support get to and framework unwavering quality are paramount.
Installation Instructions
- Preparation: Guarantee pipe closes are cut square and deburred
- Groove Assessment: Confirm groove measurements coordinate AWWA C606 specifications
- Gasket Arrangement: Position gaskets accurately in coupling housings
- Assembly: Adjust channels with cross outlets and introduce couplings
- Tightening: Torque jolts to producer details utilizing a calibrated wrench
- Testing: Perform hydrostatic test at 1.5x working pressure
Packaging and Shipping
We carefully bundle each fitting to avoid harm amid travel. Standard bundling incorporates defensive conclusion caps and moisture-resistant wrapping. Shipping ordinarily happens inside 3-5 commerce days for standard sizes.
Quality Control
Every fitting experiences thorough testing counting dimensional confirmation, hydrostatic weight testing, and fabric composition investigation. Our quality group employments Go/No-Go gages to guarantee groove precision and conducts spectroscopic investigation to confirm fabric integrity.
OEM and Customization Services
With 26 a long time of casting involvement and yearly generation capacity of 30,000 tons, we offer customization administrations for uncommon applications. Our building group can work with you to create altered arrangements or uncommon coatings to meet your particular requirements.
Frequently Asked Questions
Q: Can I use this cross in seismic zones?
A: Yes, the flexible mechanical joint naturally accommodates building movement during seismic events.
Q: What determines the pressure rating?
A: The system pressure rating equals the lowest-rated component in your assembly, whether that's the cross or the coupling.
Q: Is field welding permitted on these fittings?
A: No, welding compromises the ductile iron structure and factory coating. Use mechanical connections only.
Contact Us
Ready to improve your piping system efficiency? Contact our technical team for product specifications, pricing, or custom solutions. We're here to help you select the right Water Supply Threaded Mechanical Cross Pipe Fitting for your application.
Email: zhiyuan@mifittings.com
Our experienced engineers are ready to assist with technical questions and provide detailed quotations for your project requirements.
